Magnesium piston technology: lightweight design and improved performance

A lightweight magnesium alloy piston from STIHL for enhanced performance for professional chainsaw users.

A man wearing protective equipment saws into a  tree trunk with a STIHL MS 400 C-M petrol chainsaw with magnesium piston

The piston: the heart of the engine

STIHL chainsaws use 2-stroke engines which, like all engines, contain a piston. The motion of the piston is transferred to the crankshaft, which in turn drives the saw chain. The piston is a central components of the engine and it moves at high speed – depending on the type of chainsaw, it could reach as many as 14,000 revolutions per minute. The piston moves continuously and rapidly inside the engine cylinder, and is exposed to high temperatures and stresses. Chainsaw pistons are not routinely serviced or replaced, which means they need to work effectively throughout the lifespan of the chainsaw, and are manufactured to be both resilient and lightweight.

Most chainsaw engine pistons are made from aluminium – a tried and tested material which guarantees a long service life. But what if there were an even lighter material which could achieve an equally high maximum rotation speed? Our development work in this area has led us to create a chainsaw which is not significantly lighter overall, but does have a substantially enhanced power-to-weight ratio. In other words, we have launched an innovative product on the market which has harnessed the weight difference to improve performance.

Magnesium piston: lightweight construction for a powerful device

A STIHL MS 400 C-M petrol chainsaw with guide bar removed and piston exposed

We have long been dedicated to the task of creating chainsaws with lightweight components. The result is a piston made from a special magnesium alloy, manufactured in our own magnesium die-cast plant. Our magnesium piston weighs less than a piston made of aluminium, and achieves an even higher maximum rotation speed. This leads to improved performance, a better power-to-weight ratio and reduced transmission of vibrations to the operator.

To make a component which can satisfy even the most demanding requirements, we produce the magnesium piston using a special die-cast process. The piston is then hardened by means of electrolysis, a chemical process which toughens the piston surface and renders it resistant to corrosion. These advanced processes produce a piston which is particularly suitable for chainsaws used in professional forestry applications, as the advantages of the new magnesium technology can be applied to the most challenging tasks.

There is currently one machine available with the new magnesium piston: the STIHL MS 400 C-M.

Close-up of a STIHL MS 400 C-M petrol chainsaw featuring magnesium piston cutting into a tree trunk.

STIHL MS 400 C-M: light and more powerful

The STIHL MS 400 C-M is the first chainsaw in the world to have a magnesium piston installed as standard. This model has a similar specification to the well-established MS 362 C-M, however the lighter magnesium alloy makes it possible to install a larger piston with no increase in weight, thereby increasing the displacement of the MS 400 C-M. As a result, we have achieved a power increase of 0.5 kilowatts and an improved power-to-weight ratio.

In conclusion this means the MS 400 C-M has higher performance, no loss of durability and only a small increase in overall weight. The MS 400 C-M is a powerful and lightweight device perfect for challenging forestry tasks such as felling and processing.

STIHL MS 400 C-M in comparison

  MS 400 C-M MS 362 C-M MS 462 C-M
Weight 5,8 kg 5,6 kg 6 kg
Performance
4,0 kW 3,5 kW 4,4 kW
Power-to-weight ratio 1,45 kg/kW 1,6 kg/kW 1,4 kg/kW

Summary: magnesium piston technology

  • The piston is the heart of the engine: its motion is transferred to the crankshaft, which then drives the saw chain
  • Pistons are exposed to high stresses, explaining why only a few materials are appropriate for them
  • Most chainsaw engine pistons are made of aluminium, but with the MS 400 C-M, STIHL has brought to market the first chainsaw in the world to feature a magnesium piston
  • The magnesium alloy is lighter than an aluminium piston, but equally as durable
  • The magnesium piston achieves a higher maximum RPM for improved performance
